Permit sets for rooftops, lofts & upper floors

By June, your client is having dinner on the roof you drew in November.

Alti Faber draws the set a building department wants to read: rooftop decks, loft additions and multi-story work, composed sheet by sheet for your architect or engineer to review and seal. Drafted in Spring Valley, NY, delivered as PDF and native DWG.

Desk hours
Daily 10am–7pm
Deck set from
$640 · 5 business days
Drawing room
31 Washington Ave, Spring Valley, NY

Sheet index

What goes in, what comes back out.

Most jobs arrive as a few photographs and a sentence. Here is the trade, laid out end to end: your raw material on the first strip, the typical contents of a loft-addition set on the second.

In What you send us
01 Phone photos from four corners
02 Hand sketch with tape dimensions
03 Property survey, if one exists
04 The old permit card
05 Parapet height, measured twice
06 A note reading “client wants a pergola”
07 Existing drawings, in any condition
Out What comes back
G-001 Cover, legend & code summary
A-101 Existing & demolition plan
A-102 Proposed loft plan
A-103 Roof & deck plan
A-201 Elevations
A-301 Building & wall sections
A-401 Stair, hatch & guardrail details
A-501 Egress & fire-separation diagram
S-101 Framing plan
S-201 Connection details
E-001 Energy-code worksheet

The house rule

A drawing that makes a plan reviewer pick up the phone has failed. So we answer the question on the sheet, before it’s asked.

— The drafting desk, Alti Faber

  • Layers named in English“Parapet-existing”, not “Layer 7”. Open the DWG in ten years and still read it.
  • One datum, statedEvery dimension is chained from a reference we mark on the sheet, never assumed.
  • Assumptions flaggedAnything we couldn’t verify from your notes is clouded and listed on the cover.

Why the sets read well

Drafting is a quiet trade. Ours is organised around the first question a reviewer asks.

A permit set is read by a stranger holding a stamp and a deadline. Each sheet we draw is composed for that reader: findings up front, dimensions chained from one datum, and notes that say what the contractor will actually build.

01

Drawn from the roof down

We begin at the parapet, drainage and structure, not at a stock floor plan. Guardrail height, stair headroom and hatch clearances get their own detail sheet.

02

Sheets in the order reviewers hunt for them

Code summary, existing conditions, proposed work, then details. Nobody pages backward looking for the egress diagram.

03

Native DWG, yours to keep

You receive the PDF set for review and the working DWG with xrefs bound and layers labelled, so the next consultant doesn’t have to start over.

04

Comment letters answered in writing

When the building department responds, each comment gets a reply that cites the revised sheet and detail number.

05

A desk that is open on weekends

Roof measurements happen on Saturdays. So does our phone: daily 10am–7pm, at (914) 522-8697.

The terms, in figures

Four numbers worth knowing before you call.

5

Business days

To first issue of a single-roof deck set with stair and hatch or bulkhead.

2

Revision rounds

Included in every package price, before an hourly or per-round charge applies.

$640

Deck set, from

The entry price for a rooftop deck set. Loft additions begin at $1,875.

7

Days a week

The desk answers the phone and email daily, 10am to 7pm.

The route a drawing takes

From a phone photo to a set that’s ready for the stamp.

Phase 01 · Intake

Send us the roof.

Four corner photographs, a tape-measured sketch, the address. If drawings exist, send them; if not, we build existing conditions from your notes. The reply carries a scope, a sheet list and a price.

  • Reply with scope and price within the working day
  • Assumptions listed before drawing begins
31′-6″ A-103 · Roof plan
Black-and-white photograph of a rooftop deck frame at dusk with a roll of drawings and a tape measure
Phase 02 · Drafting

We draw from the parapet down.

Roof plan first, then framing, then the details a reviewer circles. You get a PDF at the halfway mark, while changes are still cheap to make.

  • Halfway review before sheets are finalised
  • Two revision rounds included
Phase 03 · Issue & answer

Issue the set, then answer the comments.

The final PDF and DWG go to your architect or engineer of record for review and seal. When the building department writes back, we revise against their letter, not against a guess.

  • PDF set plus native DWG
  • Comment-letter replies priced at $190
42′-0″ A-301 · Building section

Packages & price list

Priced per project, billed by invoice.

Each package names the sheets you receive. Pay the invoice by ACH, check or card; there is no cart and nothing renews. Bespoke scope? Send the address and we’ll quote it.

Entry

Rooftop Deck Set

From$640

One roof, one deck, with a stair and a hatch or bulkhead.

  • 5–7 sheets: cover & code notes, roof plan, framing, guardrail & stair details
  • First issue in 5 business days
  • Two revision rounds, PDF + DWG
Start a deck set
Most picked

Loft Addition Set

From$1,875

An added loft level or a rooftop room on an existing building.

  • 10–14 sheets: existing & demo, proposed plans, elevations, sections, framing
  • Egress and fire-separation diagram plus energy-code worksheet
  • Halfway PDF review, two revision rounds, PDF + DWG
Draw my loft
Field work

As-Built Record

Per floor$385

Measured plans of what is standing today, drawn from your field notes.

  • Plan, with every assumed dimension flagged
  • Roof plan add-on: $215
  • Layered DWG you can build on later
Request an as-built

Line items

The ledger, for everything outside a package.

Extra revision round
$145
Written reply to a building-department comment letter
$190
48-hour rush on any set
+$260
Extra floor on an as-built
$385
Clean-up of existing drawings into layered DWG
$215

Before you press send

What to bring on day one.

A half-page of facts saves a day of questions:

  • The street address and tax-lot, if you have it
  • Photos from each corner of the roof, plus the stair or hatch
  • Overall length and width, parapet height, floor-to-floor height
  • Existing drawings or the last permit, in any condition
  • The name of your architect or engineer of record

Questions, answered plainly

The usual hesitations.

Do you stamp the drawings?

We draft; we don’t seal. Each set is built to go to your architect or engineer of record, who reviews it and applies the seal. If a job needs one and you don’t have one, say so at kickoff and we’ll tell you what the building department is likely to ask for.

How long does a rooftop deck set take?

Five business days to first issue for a single-roof deck with a stair and a hatch or bulkhead. Loft additions run longer, so we quote the date alongside the price.

What if the building department writes back?

Two revision rounds are inside every package. A formal comment letter is answered separately for $190, with each reply pointing to the revised sheet and detail.

Can you work from photos alone?

Photos show us the building; dimensions let us draw it. A tape-measured sketch of the main runs is enough, and every dimension we assumed is clouded on the sheet.

Which files do I receive?

A PDF set for review and the native DWG with plain-English layer names, so you can keep building on it.

Open daily, 10am–7pm

Send the address and one photo of the roof.

We’ll answer with a sheet list, a delivery date and a price, in that order. Call the desk or write; both reach the same two people.

Call the desk Send the roof
